CMER Hydraulic Motors

Hydraulic Motors by Hydromot are characterised by their high quality and reasonable price. Our CMER hydraulic motors are compatible with the hydraulic motors White (RE series)
For further information please visit our guide.

Filter
Failed to retrieve the available filter values!
1 to 16 (from a total of 44)

CMER Hydraulic Motor FAQ


What is the maximum continuous operating speed for the CMER 250 hydraulic motor?

The maximum continuous operating speed for the CMER 250 hydraulic motor is 290 rpm.


What different mounting flange options are available for CMER hydraulic motors?

CMER hydraulic motors offer three mounting flange options:

  • F4: Oval flange with 4 holes, SAE A standard
  • F6: Oval flange with 6 holes, SAE A standard
  • W: Wheel flange


What is the displacement volume of the CMER 375 hydraulic motor?

The CMER 375 hydraulic motor has a displacement volume of 371 cm³/revolution.


What output shafts are available for CMER hydraulic motors?

Several output shaft options are available:

  • CO: Ø31.75 mm (1 1⁄4") cylindrical with key 7.96x7x36.5
  • C: Ø32 mm cylindrical with key A10x8x36
  • SH: Ø31.75 mm (1 1⁄4") splined, 14 teeth, DP 12/24
  • K: Tapered 1:8 with key 7.96x7.96x25.4
  • CO1: Ø25.4 mm (1") cylindrical with key 1⁄4"x1⁄4"x11⁄4"
  • C25: Ø25 mm cylindrical with key 8x7x32
  • S: Ø25.32 mm splined (SAE 6B)


What is the maximum allowable radial shaft load for a CMER motor with an F4 mounting flange?

The maximum allowable radial shaft load depends on the shaft extension length and operating speed. Refer to the "Radial Shaft Load CMER" chart in the catalog for specific values. Exceeding the maximum load increases the risk of shaft failure.


How long can the CMER 300 operate intermittently?

Intermittent operation for all CMER motors is limited to 6 seconds per minute.


What is the maximum operating pressure for a CMER 540 hydraulic motor?

The maximum operating pressure (peak load) for the CMER 540 hydraulic motor is 205 bar. This value applies for 0.6 seconds per minute.


How heavy is a CMER 750 hydraulic motor with a wheel mounting flange (W)?

A CMER 750 hydraulic motor with a wheel mounting flange (W) weighs 16.0 kg.
