Hydraulic Cylinder, Double Acting, Hinge, Piston Ø 32mm, Rod Ø 20mm, Selectable stroke

Hydraulic Cylinder, Double Acting, Hinge, Piston Ø 32mm, Rod Ø 20mm, Selectable stroke

This cylinder is characterised by its high quality and  reasonable price.

Its features are as follows:

• double acting cylinder with hinge
• Maximum compression power: 1,6 tons
• Ø piston: 32mm
• Ø piston rod: 20mm
• selectable stroke from 50mm up to 1000 mm
• max. pressure: 200 bar
• max. pass speed: 0,5 m/s

Dimensions:





ØA	ØB	STROKE	E	C	D	F	G	H	I	J	K	L	M (BSP)	WEIGHT [kg]
20	32	50	205	16	16,2	35	40	28	30	47	35	9,5	1/4"	1,7
20	32	100	255	16	16,2	35	40	28	30	47	35	9,5	1/4"	2,0
20	32	150	305	16	16,2	35	40	28	30	47	35	9,5	1/4"	2,3
20	32	200	355	16	16,2	35	40	28	30	47	35	9,5	1/4"	2,6
20	32	250	405	16	16,2	35	40	28	30	47	35	9,5	1/4"	2,9
20	32	300	455	16	16,2	35	40	28	30	47	35	9,5	1/4"	3,2
20	32	350	505	16	16,2	35	40	28	30	47	35	9,5	1/4"	3,4
20	32	400	555	16	16,2	35	40	28	30	47	35	9,5	1/4"	3,6
20	32	500	655	16	16,2	35	40	28	30	47	35	9,5	1/4"	4,2
20	32	600	755	16	16,2	35	40	28	30	47	35	9,5	1/4"	4,8
20	32	700	855	16	16,2	35	40	28	30	47	35	9,5	1/4"	5,3
20	32	900	1055	16	16,2	35	40	28	30	47	35	9,5	1/4"	6,8
20	32	1000	1155	16	16,2	35	40	28	30	47	35	9,5	1/4"	7,2

Hydraulic component for integration in hydraulic systems

All our hydraulic products are new, unused and in OEM quality (except when explicitly declared otherwise). Should a particular item not be in stock or not be represented here, please don’t hesitate to contact us. We will immediately try to find an appropriate solution pertaining to your given specifications. Moreover, we are constantly expanding our product range to offer you a wide variety of hydraulic components at reasonable prices. Hydromot hydraulics – always an excellent choice at low prices!
