R15 (SAE 100 R15 - ISO 3862 Type R15)

  • Primary application: General high pressure hydraulic applications

  • Applicable specifications: SAE 100 R15 - ISO 3862 Type R15

  • Reinforcement: 4 (from nominal width 31: 6) high tensile steel spirals

  • Inner tube​: Synthetic rubber, black

  • Cover: Synthetic rubber, wear resistant, black

  • Temperature range and resistance: - 40 ° C to + 100 ° C, water and water-based media up to + 70 ° C; Hydraulic oil based on mineral oil and water emulsions and aqueous glycol solutions

Technical data R15

Product image Hydraulic hose according to SAE 100 R15 DN25
Hydraulic hose according to SAE 100 R15 DN25

  • Nominal width: 25

  • Size: 16

  • Inch: 1

  • Inner diameter: 25,7 mm

  • Outer diameter: max. 42,9 mm

  • R min.: 330 mm

  • Working pressure: 420 bar

  • Burstpressure: 1680 bar
51,76 EUR
51,76 EUR per meter
plus 17% tax
Product image Hydraulic hose according to SAE 100 R15 DN31
SOLD OUT
Hydraulic hose according to SAE 100 R15 DN31

  • Nominal width: 31

  • Size: 20

  • Inch: 1 1/4

  • Inner diameter: 32,2 mm

  • Outer diameter: max. 51,5 mm

  • R min.: 445 mm

  • Working pressure: 420 bar

  • Burstpressure: 1680 bar
86,02 EUR
86,02 EUR per meter
plus 17% tax
1 to 2 (from a total of 2)
