Hydraulic Cylinder, Double Acting, Ball joint, Piston Ø 70mm, Rod Ø 40mm, Selectable stroke

Hydraulic Cylinder, Double Acting, Ball joint, Piston Ø 70mm, Rod Ø 40mm, Selectable stroke

This cylinder is characterised by its high quality and  reasonable price.

Its features are as follows:

• double acting cylinder with hinge
• Maximum compression power: 7,6 tons
• Ø piston: 70mm
• Ø piston rod: 40mm
• selectable stroke from 200mm up to 700 mm
• max. pressure: 200 bar
• max. pass speed: 0,5 m/s

Dimensions:





ØA	ØB	STROKE	E	C	D	F	G	H	I	J	K	L	M (BSP)	WEIGHT [kg]
40	70	200	470	30	35	61	80	98	70	94	49	15	3/8"	11,03
40	70	300	570	30	35	61	80	98	70	94	49	15	3/8"	12,94
40	70	400	670	30	35	61	80	98	70	94	49	15	3/8"	14,85
40	70	500	770	30	35	61	80	98	70	94	49	15	3/8"	16,76
40	70	600	870	30	35	61	80	98	70	94	49	15	3/8"	18,67
40	70	700	970	30	35	61	80	98	70	94	49	15	3/8"	20,58

Hydraulic component for integration in hydraulic systems

All our hydraulic products are new, unused and in OEM quality (except when explicitly declared otherwise). Should a particular item not be in stock or not be represented here, please don’t hesitate to contact us. We will immediately try to find an appropriate solution pertaining to your given specifications. Moreover, we are constantly expanding our product range to offer you a wide variety of hydraulic components at reasonable prices. Hydromot hydraulics – always an excellent choice at low prices!
