Hydraulic Cylinder, Double Acting, Hinge, Piston Ø 60mm, Rod Ø 30mm, Selectable stroke

Hydraulic Cylinder, Double Acting, Hinge, Piston Ø 60mm, Rod Ø 30mm, Selectable stroke

This cylinder is characterised by its high quality and  reasonable price.

Its features are as follows:

• double acting cylinder with hinge
• Maximum compression power: 5,6 tons
• Ø piston: 60mm
• Ø piston rod: 30mm
• selectable stroke from 100mm up to 1000 mm
• max. pressure: 200 bar
• max. pass speed: 0,5 m/s

Dimensions:





ØA	ØB	STROKE	E	C	D	F	G	H	I	J	K	L	M (BSP)	WEIGHT [kg]
30	60	100	300	22	25,25	45	70	83	40	43	43	15	3/8"	5,4
30	60	150	350	22	25,25	45	70	83	40	43	43	15	3/8"	6,3
30	60	200	400	22	25,25	45	70	83	40	43	43	15	3/8"	7
30	60	250	450	22	25,25	45	70	83	40	43	43	15	3/8"	7,63
30	60	300	500	22	25,25	45	70	83	40	43	43	15	3/8"	8,1
30	60	350	550	22	25,25	45	70	83	40	43	43	15	3/8"	9,1
30	60	400	600	22	25,25	45	70	83	40	43	43	15	3/8"	9,5
30	60	450	650	22	25,25	45	70	83	40	43	43	15	3/8"	10,4
30	60	500	700	22	25,25	45	70	83	40	43	43	15	3/8"	10,8
30	60	600	800	22	25,25	45	70	83	40	43	43	15	3/8"	12,2
30	60	700	900	22	25,25	45	70	83	40	43	43	15	3/8"	13,5
30	60	800	1000	22	25,25	45	70	83	40	43	43	15	3/8"	15
30	60	900	1100	22	25,25	45	70	83	40	43	43	15	3/8"	16,4
30	60	1000	1200	22	25,25	45	70	83	40	43	43	15	3/8"	17,8

Hydraulic component for integration in hydraulic systems

All our hydraulic products are new, unused and in OEM quality (except when explicitly declared otherwise). Should a particular item not be in stock or not be represented here, please don’t hesitate to contact us. We will immediately try to find an appropriate solution pertaining to your given specifications. Moreover, we are constantly expanding our product range to offer you a wide variety of hydraulic components at reasonable prices. Hydromot hydraulics – always an excellent choice at low prices!
